PEL PINV -12K- Jumbo Pro T3 (H&C) 1.0 Ton Air Conditioner

Specifications

• Model: 12K Jumbo Pro
• Type: DC Inverter Heat & Cool
• Capacity: 12,000 BTU
• Power Supply: 220–240V~, 50Hz

Cooling Performance

• Cooling Capacity: 3,520 W (800–4,000 W)
• Rated Power Consumption (Cooling): 1,100 W (300–1,350 W)
• Rated Running Current (Cooling): 5.3 A (1.5–6.0 A)
• Energy Efficiency Ratio (EER): 3.20

Heating Performance

• Heating Capacity: 3,550 W (800–4,200 W)
• Rated Power Consumption (Heating): 970 W (300–1,350 W)
• Rated Running Current (Heating): 4.6 A (1.5–6.0 A)

Power Specifications

• Maximum Input Power: 1,500 W
• Maximum Input Current: 8.5 A

Airflow & Noise

• Indoor Airflow Volume: 600 m³/h
• Indoor Noise Level: 42 dB(A)
• Outdoor Noise Level: 52 dB(A)

Refrigerant & Compressor

• Refrigerant Type: R32
• Refrigerant Charge: 490 g
• Compressor Type: Rotary

Indoor Unit

• Dimensions (W × D × H): 792 × 292 × 201 mm
• Net Weight: 8.5 kg

Outdoor Unit

• Dimensions (W × D × H): 705 × 279 × 530 mm
• Net Weight: 22.5 kg
