Features:
- Energy Efficiency Class A++
- Silent Mode Yes
- Fast Cooling Mode:Â Yes
- SEER (W/W, Seasonal Efficiency)Â 6.10
Technical Specifications Details
Capacity
- Capacity (Cooling, Btu/hour)Â 17061
- Capacity (Heating, Btu/hour)Â 20473
- Capacity (Cooling, Min – Max, Btu/hour)Â 5459 ~ 22179
- Capacity (Heating, Min – Max, Btu/hour)Â 4095 ~ 24567
- Capacity (Cooling, kW)Â 5.0
- Capacity (Heating, kW)Â 6.0
- Capacity (Cooling, Min – Max, kW)Â 1.6 ~ 6.5
- Capacity (Heating, Min – Max, kW)Â 1.2 ~ 7.2
Energy Efficiency
- SEER (W/W, Seasonal Efficiency)Â 6.10
- SCOP (W/W, Seasonal Efficiency)Â 3.80
- EER (Cooling, W/W)Â 3.45
- COP (Heating, W/W)Â 3.43
- EER (Refrigerant, Btu/hW)Â 11.e77
- COP (Heating, Btu/hW)Â 11.70
- Energy Efficiency Class A++ for Cooling
Noise Level
- Sound Power Level (Indoor Unit, Cooling, dBA)Â 58
- Sound Power Level (Outdoor Unit, Cooling, dBA)Â 65
- Sound Pressure Level (Indoor Unit, High / Low dBA)Â 41 / 27
- Sound Pressure Level (Outdoor Unit, High dBA)Â 51
Electrical Information
- Power Supply (Φ/V/Hz) 1 / 220 – 240 / 50
- Power Consumption (Cooling, W)Â 1450
- Power Consumption (Heating, W)Â 1750
- Operating Current (Cooling, A)Â 6.6
- Operating Current (Heating, A)Â 7.9
Physical Characteristics
- Gross Dimensions (Outdoor Unit, W x H x D, mm x mm x mm)Â 1115 x 290 x 375
- Gross Dimensions (Indoor Unit, W x H x D, mm x mm x mm)Â 1023 x 724 x 413
- Net Dimensions (Indoor Unit, W x H x D, mm x mm x mm)Â 1055 x 299 x 215
- Net Dimensions (Outdoor Unit, W x H x D, mm x mm x mm)Â 880 x 638 x 310
- Gross Weight (Indoor Unit, kg)Â 13.2
- Gross Weight (Outdoor Unit, kg)Â 45.2
- Net Weight (Indoor Unit, kg)Â 11.5
- Net Weight (Outdoor Unit, kg)Â 39.8
- Loading Quantity (without 20 / 40 / 40 Hft pipe)Â 65 / 138 / 154
Technical Specifications
- Copper Pipeline Length (Max., m)Â Â 5.0
- Copper Pipeline Height (Max. m)Â 1.5
- Copper Pipe Fitting / Liquid Line (mm)Â 6.35
- Copper Pipe Fitting / Gas Line (mm)Â 12.7
- Moisture Removal (L/hr)Â 2.0
- Air Circulation (Cooling, m³/min) 16.5
- Refrigerant (Type)Â R410A
- Cooler (Filling, kg)Â 1.30
- Refrigerant (Charging, tCO2e)Â 2.71
- Operating Temperature Range (Cooling, °C) -10 ~ 46
- Operating Temperature Range (Heating, °C) -15 ~ 24
- Outdoor Unit (Compressor Type)Â BLDC
- Corrosion-resistant condenser (outdoor unit)Â Yes
Indoor Unit Specifications
- Indoor Unit Vane Direction (Up/Down)Â Automatic
- Indoor Unit Vane Direction (Left / Right)Â Manual
- Fan Speed ​​Levels (Cooling Mode / Fan Mode) 5 / 4
Air Purifier
- PM 1.0 Filter:Â No
- Tri Care Filter No
- Practical Filter Plus Yes
- Indoor Unit Automatic Cleaning (Self-Cleaning) Yes
Ease
- SmartThings No
- AI-powered automatic cooling:Â No
- Smart Eye No
- Filter Clean Indicator:Â Yes
- Indoor Unit Temperature Display:Â Yes
- Screen On/Off Yes
- Signal Sound On/Off Yes
- 24-Hour Timer Yes
- Automatic Mode Switching Yes
- Automatic Restart Yes
Indoor Unit Operating Modes
- Automatic Mode Yes
- Fast Cooling Mode:Â Yes
- Good Sleep Mode Yes
- Eco Mode Yes
- Dehumidification Mode:Â Yes
- Fan Mode Yes
- Silent Mode Yes
Connection
- Built-in Wi-Fi:Â Â Â No / Not Available
Mobile Application
- Usage with SmartThings App:Â No
